Description
Stirling Undercounter Ultralow Temperature Freezer
The Stirling Ultracold Undercounter Freezer model SU105UE is a compact ultra-low temperature freezer. It is ideal for personal storage and situations where larger volume ULT freezers might otherwise remain half empty. It delivers full performance ultra-low storage for undercounter, benchtop or stacked installation.
Stirling Ultracold Undercounter Freezer model SU105UE Specifications
- Model: SU105UE
- Capacity: 3.7 cu ft
- Temp range: -20°C to -86°C
- Auto-voltage detection
- 90-day warranty
Stirling Ultracold Undercounter Freezer model SU105UE Features
These undercounter freezers feature a 3.7 cu.ft. cabinet that delivers stable, uniform -20°C to -86°C storage at a fraction of the operating cost of conventional cascade refrigeration systems. The SU105UE models combine the performance of a unique free-piston Stirling engine with an efficient, thin-wall, non-CFC urethane foam and vacuum insulated cabinet. This permits high-performance, ultra-low temperature storage capacity in an undercounter, benchtop, or stacked cabinet configuration.
The Stirling integral control, alarm, and monitoring system includes an intuitive graphic user interface to display operating temperature, reserve cooling capacity, status functions, and performance metrics for field troubleshooting. Secure touchpad inputs permit access to and programming for all control functions and alarm setpoints.
The SU105UE models have an auto-voltage range of 85V to 264V, 50 or 60Hz. This auto-voltage capability allows the SU105UE models to operate on any outlet without factory modification (the user will need to install the specific cord that fits their receptacle).
Testing
Most of our equipment is used and reconditioned. Our technicians verify the accuracy of temperature controls and readouts of all freezers, making sure that the units hold temperature to within the manufacturer specified tolerance. We replace any hardware or parts as is necessary and if needed replace refrigerant. We clean all freezers thoroughly prior to shipment.
Pictures
The photos above are representative. Please bear in mind that the equipment shown is currently in storage in our warehouse and that in addition to testing each machine we will clean all the equipment thoroughly prior to shipment.
We often have multiple units of each model in stock and sometimes we’re unable to feature photos of every single unit. At your request, we can provide photos of the equipment in your order after it has been tested and cleaned.
Stirling Undercounter Ultralow Temperature Freezer – Additional Specifications
| External dimensions | 27”W x 28”D x 34”H |
| Internal dimensions | 18”W x 17”D x 21”H |
| Capacity | 3.7 Cu Ft |
| Temperature range | -20°C to -86°C |
| Electrical requirements | 120 V, 60 Hz or 208/230 V, 60 Hz |
| Shipping weight | 266 lbs |
For inquiries about the Stirling SU105UE, please give us a call at 978-521-2221, or fill out the form on this page.
Stirling SU105UE ultracold FAQs
Q: Is the Stirling SU105UE stackable?
A: Yes, these units can be used as undercounter models, benchtop models, standalones, or can be stacked vertically to utilize a compact footprint for two separate ultralow, -86°C chambers.
Q: How can the Stirling SU105UE run at both -20°C and -86°C? Is a wide temperature range like this typical of ultralow freezers?
A: No, a temperature range this wide is very unusual. The piston free engine, designed and built by Stirling, allows for this wide range, unlike a more typical dual stage compressor model which can only be set from -50°C to -86°C.
Q: Are boxes and/or racks included with the purchase of a Striling Ultracold SU105UE?
A: While we may have storage racks available, they are generally not included in the standard purchase of any of our ultralow freezers. Please call or email us for pricing and availability.
Q: How do you test the Stirling SU105UE to insure proper functionality?
A: Our technicians run each ultralow freezer in our shop for an extended period of time (anywhere from seven to twenty days, depending on make, model, customer preference, performance history, etc.) to make sure that the unit reaches and holds temperature at the set point. We typically test these units on an empty load, meaning that there are no samples in the chamber during testing. We also examine each SU105UE for signs of wear, corrosion, or damage, and verify other key performance specifications such as recovery time after door opening, built-in data logging, and other functions.
Q: How does the Stirling SU105UE operate so efficiently?
A: Stirling ultracold freezers feature a piston-free engine that continually modulates and eliminates the on-off cycle of a traditional, dual-stage compressor-based system. Combined with the thin-wall, vacuum insulated panels, this provides for efficiency along with quiet operation and quick recovery time. According to manufacturer specifications labs can expect to see energy savings of 70% to 75%.
Q: Is this ultralow freezer compatible with LN2 backup systems for emergency use?
A: Yes, both LN2 and CO2 back-up systems can be purchased for installation with the Stirling SU105UE ultralow freezer.
