Description
Thermo Scientific CryoPlus 1 LN2 storage system
The Thermo Scientific CryoPlus 1 LN2 storage system combines liquid nitrogen storage reliability and microprocessor technology. The liquid level sensor and fill port are located with the vacuum space to ensure maximum storage area and protection of the sensor from damaged while the microprocessor controls allow precise and accurate control over 16 parameters as well as audio and visual alarms.
Thermo Scientific CryoPlus 1 LN2 storage system features
- 200L capacity
- Static evaporation rate: 5L/day
- Static holding time: 40 days
- 90 day warranty
The exterior cabinet is made of 18-gauge cold-rolled steel with powder coated paint for durability and chipping and rust resistance. The Thermo Cryocool 742 can accept a total of 13,000 vials of 2.0mL each.
16 preset audible and visual alarm combinations provide maximum product protection. Automatic defogger incorporated into the manual fill index to improve visibility during retrieval. Liquid level sensor and fill port within vacuum space, for maximum storage and sensor protection. Front-mounted key lock and rear-mounted recessed power switch; control panel can also be locked. Temperature sleeve (included) provides colder temperatures and efficient vapor phase operation.
Precise liquid level control with over 16 parameters; with autofill system. Control panel mounted on top for convenient access and easy touchpad programming. Digital temperature display sensor located under the lid; this indicates the highest temperature reading inside the tank. 24 tricolor LEDs continuously display actual liquid nitrogen level and high-level/low-level setpoints. Alarm contacts for remote monitoring of storage tank conditions.
Testing
Most of our equipment is used and reconditioned. Our technicians test all equipment to confirm that it operates properly and to the manufacturer’s specifications. While we can’t test for a specific analytical application, we will do our best to simulate the conditions under which the equipment will be run.
If you have particular testing requirements or requests please let us know and we’ll work with you to make sure these requirements are addressed during testing.
Pictures
The Thermo Scientific CryoPlus 1 LN2 storage system photos above are representative. The equipment shown is currently in storage in our warehouse. In addition to testing each machine we clean all equipment thoroughly prior to shipment.
We often have multiple units of each model in stock and sometimes we’re unable to feature pictures of every single unit. At your request, we can provide pictures of the equipment in your order after it has been tested and cleaned.
Thermo CryoPlus 1 specifications
| Type | Auto-Fill LN2 Cryo |
| Capacity (English) | 3.178 cu. ft. |
| Capacity (Metric) | 90 L |
| No. of Doors | 1 |
| Insulation | Polyurethane |
| Interior | Stainless Steel (Chamber) |
| Certifications/Compliance | UL listed to U.S. and Canadian requirements |
| Dimensions (L x W x H) Exterior | 26 x 21.5 x 41 in. (66 x 54.6 x 104 cm) |
| Depth (English) Interior | 27.5 in. |
| Depth (Metric) Interior | 69.9 cm |
| Height (English) Exterior | 41 in. |
| Height (Metric) Exterior | 104 cm |
| Length (English) Exterior | 26 in. |
| Length (Metric) Exterior | 66 cm |
| Width (English) Exterior | 21.5 in. |
| Width (Metric) Exterior | 54.6 cm |
| Diameter (English) | 16 in. |
| Diameter (Metric) | 40.6 cm |
| Monitoring Options | Remote Alarm Contacts |
| Voltage | 100/120 V |
| Electrical Requirements | 100 – 120 V 50/60 Hz |
| Frequency | 50/60 Hz |
| Vial Capacity | 5500 to 6318 |
| Shipping Weight (English) | 260 lb. |
| Shipping Weight (Metric) | 117.9 kg |
| Weight (English) | 214 lb. |
| Weight (Metric) | 97.1 kg |
| Holds | Vials (38,500 x 2 mL) |
